Burndy GRL5 Ground Rod Lug 5/8"

Overview

Burndy GRL5 Ground Rod Lug 5/8"

Product Specifications

• UPC: 78181005182
• Approval: UL 467, CSA
• Used On: Grounding Wire to Rod, Direct Burial
• Additional Information: RoHS Compliant
• Catalog Number: GRL5
• Brand Name: Burndy
• Model: GRL
• Conductor Size: 10 to 2 AWG Stranded (Copper)
• Rod Size: 5/8 Inch
• Size: 0.94 Inch Width x 1.34 Inch Height
• Installation: Hex Head Screw
• Material: Copper Alloy
• Catalog Description: MECHANICAL GROUNDING CONNECTOR, 10 AWG - 2 AWG, 5/8" GROUND ROD.
• Category: Ground Rods & Grounding Systems
• Full Technical Description: Copper Alloy Material; 0.94 Inch Width X 1.34 Inch Height Size; Grounding Wire to Rod, Direct Burial Used on; Hex Head Screw Installation; UL 467, CSA Approval; 10 to 2 AWG Stranded (Copper) Conductor Size; 5/8 Inch Rod Size; RoHS Compliant; GRL Model
• Manufacturer: Burndy Products
• Manufacturer Brand: Burndy Products
• Sub Category: Conduit To Rod Clamp
• Unspsc: 39121408
• UPC 12 Digit: 781810051825
• SKU Name: grl5 burndy

Resources

• Technical Drawing
• Technical Line Drawing
• Manufacturer Spec Sheet
