Midwest GS3161B12UL Heavy-Duty Transfer Switch 100/100A 3P 600V Steel

Overview

Midwest GS3161B12UL Heavy-Duty Transfer Switch 100/100A 3P 600V Steel

Product Specifications

• UPC: 78456720618
• Enclosure: NEMA 3R
• Height: 26 Inch
• Width: 13 Inch
• Depth: 6-3/4 Inch
• Application: Generator
• Approval: UL (Canada and US)
• Additional Information: Cabinet Size 12 Inch x 23 Inch; Number of Poles 3; Material G90 Galvanized Steel; Finish Polyester Powder Coated; Includes 1-1/4 Inch Hub
• Catalog Number: GS3161B12UL
• Type: Manual
• Voltage Rating: 120/240 VAC 1-Phase, 600 VAC 3-Phase
• Main Current Rating: 100 Ampere
• Emergency Current Rating: 100 Ampere
• Short Circuit Rating: 10000 Ampere
• Wire Type: Aluminum/Copper
• Wire Size: 12 AWG to 1/0 KCMIL
• Catalog Description: SINGLE PHASE 120/240 VOLTS AC SWITCH NEUTRALNOTE: UNIT IS RATED 600V IF FIELD INSTALLED WITH NEU102 - ORDERED SEPARATELY
• Category: Non-Fusible Double Throw Safety Switches
• Full Technical Description: Manual Type; 13 Inch; 26 Inch; 6-3/4 Inch; 12 AWG to 1/0 kcmil Wire Size; UL (Canada and Us) Approval; Generator Application; 120/240 VAC 1-Phase, 600 VAC 3-Phase Voltage Rating; NEMA 3R Enclosure; Aluminum/Copper Wire Type; 10000 Ampere Short Circuit Rating; 100 Ampere Emergency Current Rating; 100 Ampere Main Current Rating; Cabinet Size 12 Inch X 23 Inch; Number of Poles 3; Material G90 Galvanized Steel; Finish Polyester Powder Coated; Includes 1-1/4 Inch Hub
• Manufacturer: Midwest Electric Products, Inc.
• Manufacturer Brand: Midwest Electric Products, Inc.
• Sub Category: Transfer Switch
• Unspsc: 39122214
• UPC 12 Digit: 784567206180
• SKU Name: midwest gs3161b12ul

Resources

• Manufacturer Spec Sheet
