Penn-Union KD-R05 4/0-AWG Press-On Connector

Overview

High-strength steel construction for enhanced durability, Precision-engineered for optimal performance and minimal vibration, Easy installation and maintenance, Compatible with a wide range of applications

Product Specifications

• Category: Large Terminals & Connectors
• Full Technical Description: 3/0 AWG (Standard, ACSR and Aluminum Alloy), 4/0 AWG (Compact, ACSR) min. Run Conductor Size; 4/0 AWG (Standard, ACSR and Aluminum Alloy), 266 MCM (Compact, ACSR) Max. Run Conductor Size; 1 AWG (Standard, ACSR and Aluminum Alloy), 1/0 AWG (Compact, ACSR) min. Tap Conductor Size; 2/0 AWG (Standard, ACSR and Aluminum Alloy, Compact, ACSR) Max. Tap Conductor Size; H Shape; Copper/Aluminum Conductor Material; RUS Approval; High Conductivity Aluminum Body Material; D Die Index; RoHS Compliant; Overall Dimension 2.25 Inch Length X 0.89 Inch Width X 1.44 Inch Height
• Manufacturer: Penn-Union Corp.
• Manufacturer Brand: Penn-Union Corp.
• Sub Category: Compression Cable Tap
• Unspsc: 39121409
• UPC 12 Digit: 785037402385
• SKU Name: KDR05 PENNUNION
