T&B STEX100 Aluminum Extreme Explosion-Proof Fitting Teck Cable- 1"

Overview

IP68 rated for superior dust and moisture resistance, Corrosion-resistant finish for enhanced durability, Easy access hinged door with lockable handle, Multiple knockouts for versatile installation options

Product Specifications

• UPC: 78621095252
• Enclosure: NEMA 4/4X
• Approval: UL, CSA
• Additional Information: RoHS Compliant; Type Straight, Quick-Turn Lock; Throat Type Collar Ring, Bushing, Gland Nut; Constructional Feature Explosionproof, Water Tight, Water/Oil Resistant
• Catalog Number: STEX100
• Brand Name: STAR TECK[R], STAR TECK EXTREME[R]
• Model: STEX
• Trade Size: 1 Inch NPT
• Cable Type: Jacketed Metal Clad, MC-HL, Teck
• Cable Size: 0.86 to 1.205 Inch
• Diameter: 2.3 Inch
• Material: Copper-Free Aluminum
• Catalog Description: STAR TECK EXTREME HAZARDOUS LOCATION ALUMINUM JACKETED CABLE FITTING. HUB SIZE OF 1 INCH. RANGE OVER JACKET FROM 0.860 - 1.205 INCH.
• Category: Rigid Conduit Fittings - Aluminum
• Full Technical Description: Copper-Free Aluminum Material; Jacketed Metal Clad, MC-Hl, TECK Cable Type; 0.86 to 1.205 Inch Cable Size; UL, CSA Approval; 2.3 Inch Diameter; NEMA 4/4X Enclosure; 1 Inch NPT Trade Size; EXTREME[R] Brand; RoHS Compliant; Type Straight, Quick-Turn Lock; Throat Type Collar Ring, Bushing, Gland Nut; Constructional Feature Explosionproof, Water Tight, Water/Oil Resistant; STEX Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Explosionproof Armored/Metal Clad Cable Terminator
• Unspsc: 39121311
• UPC 12 Digit: 786210952529
• SKU Name: T&B STEX100
