Burndy YA26LNT14 2/0Awg 1-Hole Lug

Overview

Burndy YA26LNT14 2/0Awg 1-Hole Lug

Product Specifications

• Catalog Description: 2/0 AWG CU, ONE HOLE, 1/4 STANDARD BARREL, INSPECTION WINDOW, NARROW TONGUE INTERNAL CHAMFER, TIN PLATED, UL/CSA, 90C, UP TO 35KV, BLACK COLOR CODE, 13 DIE INDEX.
• Full Technical Description: Electro Tin Plated Copper Material; Black Color; 2.02 Inch Overall Length; 0.94 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 600 V to 35 kV Voltage Rating; 2/0 AWG Stranded Conductor Size; 1/4 Inch Stud Size; 13 Die Index; 0.48 Inch W X 0.12 Inch Thk Pad Size; 1 Pad Hole(S); Narrow, Standard, Straight Barrel Type; HYLUG[T], BURNDY[R] Brand; RoHS Compatible; Cable Entry Type Beveled, Chamfered; Wire Strip Length 1 Inch; Temperature Rating 90 Deg C; YA-L-NT Model
• Manufacturer: BURNDY PRODUCTS
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 781810076613
• SKU Name: ya26lnt14 burndy

Resources

• Manufacturer Spec Sheet
• Technical Drawing
